WERNER® 7412 7400 Type IAA Step Ladder, 12 ft H Ladder, 375 lb Load, 11 Steps, Fiberglass, A14.5


Description

WERNER® Step Ladder, Type IAA, Series: 7400, 12 ft Ladder Height, 375 lb, ANSI Code: A14.5, Fiberglass, 11 Steps, 79-7/8 in Base Spread, 35-1/2 in Bottom Width, 3 in W Tread

Built to last, the Werner 375-pound duty rated 7412 Fiberglass 12 ft Step Ladder is rugged and ready for the job. This ladder features extra heavy duty aluminum HolsterTop, internal spreaders and external rail shields for long lasting durability. With The Edge® bracing system and GLAS*MARK® Violator stripes on the rails, the 7400 series is built to handle the worksite and stands ready for tough jobs. Fiberglass rails are non-conductive for working near electricity.

Specifications

ANSI Code A14.5
Base Spread 79-7/8 in
Bottom Width 35-1/2 in
Ladder Height 12 ft
Load Capacity 375 lb
Material Fiberglass
Number of Steps 11
Series 7400
Tread 3 in W
Type Type IAA

Country of Origin: United States

Standards and Approvals: ANSI A14.5 (2007), OSHA Standard

Features

  • Extra heavy duty aluminum holster top
  • Thick side plates
  • Shoulder bolt and lock nut on top hinge, 4 solid aluminum rivets attach top to each front rail
  • Back-up plates reinforce all top connectors
  • Slip-resistant TRACTION-TRED® steps are double riveted and have extra wide knee braces
  • Extra heavy duty internal spreaders
  • Glas mark violator stripes on rails allow ladder to be more visible
  • The edge bracing system helps to decrease damage to rail
  • Aluminum external rail shield helps protect against abrasion damage
  • Shoe pads riveted to the edge structure
  • Every rivet backed up by metal plate or washer to protect rails
  • Energy diffusing geometry
  • 3-1/8 in front wide x 1-7/8 in rear wide rail
  • 1-3/16 in front wide x 1-3/16 in rear back wide flange
