Matco-Norca™ ZMBCPR0502 PL-0317-F Pipe Reducing Coupling, Coupling, 1 x 3/8 in Nominal, 150 lb, Malleable Iron, Black, Import


Description

Matco-Norca™, ZMBCPR0502, Pipe Reducing Coupling, Series: PL-0317-F, Fitting/Connector: Coupling, 1 x 3/8 in Nominal, 1.69 in Length, 150 lb Pressure Class, 300.23 psi Pressure, Malleable Iron, Black, -20 to 151 deg F, Import

Specifications

Domestic/Import Import
Finish Black
Fitting/Connector Type Coupling
Length 1.69 in
Material Malleable Iron
Nominal Size 1 x 3/8 in
Pressure Class 150 lb
Pressure Rating 300.23 psi
Series PL-0317-F
Temperature Rating -20 to 151 deg F

Country of Origin: Switzerland

Standards and Approvals: ANSI/ASME B16.14, FM Approved, Material conforms to ASTM A-197, UL Listed

Features

  • 100% pressure tested before leaving the factory
