Liberty Pumps® LSG204M LSG200, 50 gpm Max Flow, 10 ft Rated Head, Non-Automatic, 110 ft Max Head, 440 to 480 VAC, 3 Phase


Description

Liberty Pumps®, LSG204M, 1-Stage, Series: LSG200, 50 gpm Maximum, 10 ft Rated Head, Automatic/Non Automatic: Non-Automatic, 1-1/4 in FNPT Outlet, 110 ft Maximum Head, 2 hp, 440 to 480 VAC, 5.3 A Full Load/31 A Locked Rotor, 60 Hz Frequency, 3 ph, 3450 rpm Motor, SJOOW 25 ft Cord, 1 Service Factor, 300 Stainless Steel Impeller, 275 deg F Thermal Overload, Single Ball/Race Upper or Heavy Duty Ball/Race Lower Bearing, Fiberglass

Liberty's LSG200 series Omnivore® grinder pumps meet the demanding needs of commercial and residential sewage applications where difficult solids-handling ability is crucial. The LSG200 series features a superior cutting system made of hardened 440 stainless steel - Rockwell C58, for shearing solids into small particles prior to being passed to the discharge by the impeller under high pressure. Applications include individual or groups of homes, motels, schools, shopping centers, lakefront developments and systems requiring high pressure sewage pumping. Whether you're replacing an existing grinder pump or customizing a new sewage system, the Omnivore® can be packaged within any number of tank sizes.

Specifications

Amperage Rating 5.3 A Full Load/31 A Locked Rotor
Automatic/Non Automatic Non-Automatic
Bearing Type Single Ball/Race Upper or Heavy Duty Ball/Race Lower
Cord Type SJOOW 25 ft
Frequency Rating 60 Hz
Horsepower 2 hp
Impeller Type 300 Stainless Steel
Material Fiberglass
Maximum Flow Rate 50 gpm
Maximum Head 110 ft
Motor Speed 3450 rpm
Outlet Size 1-1/4 in FNPT
Phase 3
Rated Head 10 ft
Series LSG200
Service Factor 1
Temperature Rating 275 deg F Thermal Overload
Type 1-Stage
Voltage Rating 440 to 480 VAC

Includes: Internal Capacitor

Warranty: 3 Years

Country of Origin: United States

Standards and Approvals: CSA Certified, SSPMA Certified, PROP65: This product can expose you to chemicals including lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.

Application:
Residential and Commercial Sewage Applications

Features

  • One-piece uni-body casting
  • Quick-connect 25 in power cord
