SMC® KQ2L06-01AS KQ2 Elbow Connector, 6 mm Nominal, Tube x Male BSPT, Polybutylene Terephthalate, Import


Description

SMC® Elbow Connector, Series: KQ2, Connector Fitting/Connector, 6 mm Nominal, Tube x Male BSPT End Style, 10 mm Hex, -100 to 1 MPa Pressure, 23 to 140 deg F, Polybutylene Terephthalate, Gray/White, 10.4 in Dia, Import

KQ2 one touch, metric and inch size fittings are available in a wide variety of sizes, body styles and thread types. The use of a special profile seal allows the KQ2 to be used for a wide range of pressures from a low vacuum up to a pressure of 1 MPa. The KQ2 release collar releases both the chuck and collet to provide a low disconnection force for easy removal of the tubing.

Specifications

Color Gray/White
Dimensions 10.4 in Dia
Domestic/Import Import
End Style Tube x Male BSPT
Fitting/Connector Type Connector
Hex Size 10 mm
Material Polybutylene Terephthalate
Nominal Size 6 mm
Pressure Rating -100 to 1 MPa
Series KQ2
Temperature Rating 23 to 140 deg F

Country of Origin: Singapore

Standards and Approvals: RoHS Compliant

Features

  • Accepts FEP, PFA, nylon, soft nylon and polyurethane tubes
  • Release collar allows easy removal of tubing without causing damage to the tube
  • This is not intended for use in potable water systems
