Seco 02679426 MP12 Tip Milling Insert, MP12 Milling Tip Style, Carbide, 0.3 mm Corner Radius, Manufacturer's Grade: F40M, (3) Flutes, C5 Material Grade


Description

Seco, 02679426, Milling Insert, Tip, Series: MP12, MP12 Milling Tip, 11.7 mm Diameter Cutting, 14 mm Maximum Depth of Cut, 3 Flutes, E04 Chipbreaker, 0.3 mm Corner Radius, 90 deg Included Angle, Manufacturer's Grade: F40M, Carbide, TiAlN/TiN, Material Grade: C5

Specifications

Chipbreaker E04
Corner Radius 0.3 mm
Cutting Diameter 11.7 mm
Finish TiAlN/TiN
Included Angle 90 deg
Manufacturer's Grade F40M
Material Carbide
Material Grade C5
Maximum Depth of Cut 14 mm
Milling Tip Style MP12
Number of Flutes 3
Series MP12
Type Tip

Country of Origin: Sweden

Standards and Approvals: PROP65

Features

  • A unique, versatile end milling system that can combine different solutions for optimum accessibility and maximum stability and security,
  • PVD-coated grade for fine to medium rough milling, first choice for milling with small feeds and/or low cutting speeds
  • Excellent for milling when there is a risk of vibrations and when coolant is used
  • Recommended for machining superalloys
