Seco 02623587 SD405 CrownLoc Plus, 12.5 to 12.99 mm Drill, 5.276 in OAL, 5xD Drill Depth by Dia Ratio, 0.625 in Dia Shank, SD405 Toolholder


Description

Seco, 02623587, CrownLoc Plus, Series: SD405, 12.5 to 12.99 mm Drill, ISO 9766 Shank, 0.625 in Shank Diameter, 1.890 in Shank Length, 2.894 in Flute Length, 5.276 in Overall Length, SD405 Toolholder, 2.5591 in Maximum Drill Depth, 5xD Drill Depth by Diameter Ratio, Through Coolant (Yes/No): Yes

Specifications

Drill Depth by Diameter Ratio 5xD
Drill Size 12.5 to 12.99 mm
Flute Length 2.894 in
Maximum Drill Depth 2.5591 in
Overall Length 5.276 in
Series SD405
Shank Diameter 0.625 in
Shank Length 1.890 in
Shank Type ISO 9766
Through Coolant (Yes/No) Yes
Toolholder Type SD405

Country of Origin: Sweden

Features

  • Placeable crowns to eliminate the need for and cost of regrinding, guarantees consistently higher performance and tool life while also reducing the number of drills required in inventory, Double coolant holes through the crown permit a high volume of coolant to reach the cutting edges
  • The result is safer chip evacuation and longer tool life
