Seco 39479 Turning Insert, ANSI Code: CNMG643-MR6 TP1500, CNMG Insert, Material Grade: P, 190612 Insert, Diamond Shape, 19 Seat, Negative Rake, Neutral Cutting, For Use On Steel, Carbide, Manufacturer's Grade: TP1500


Description

Seco Turning Insert, CNMG Insert, 190612 Insert, Diamond, 12 mm Maximum Depth of Cut, 19.05 mm Inscribed Circle, 6.35 mm Thickness, 19 Seat, Negative Rake, MR6 Chipbreaker, 1.2 mm Corner Radius, 7.92 mm Hole Dia, Manufacturer's Grade: TP1500, ANSI Code: CNMG643-MR6 TP1500, ISO Code: CNMG190612-MR6 TP1500, 80 deg Included Angle, 0 deg Relief Angle, Neutral Cutting, Carbide, CVD-TiCN+Al2O3 Coated, Material Grade: P, For Use On: Steel

Specifications

ANSI Code CNMG643-MR6 TP1500
Chipbreaker MR6
Corner Radius 1.2 mm
Cutting Direction Neutral
Finish CVD-TiCN+Al2O3 Coated
For Use On Steel
Hole Diameter 7.92 mm
Included Angle 80 deg
Inscribed Circle 19.05 mm
Insert Size 190612
Insert Style CNMG
ISO Code CNMG190612-MR6 TP1500
Manufacturer's Grade TP1500
Material Carbide
Material Grade P
Maximum Depth of Cut 12 mm
Rake Negative
Relief Angle 0 deg
Seat Size 19
Shape Diamond
Thickness 6.35 mm

Country of Origin: Sweden

Application:
Medium and Roughing
