Seco 02411272 12ER Grooving Insert, 12ER Insert, 12150 Insert, Neutral Cutting, 0.059 in W Cutting, Manufacturer's Grade: CP500, Micrograin Material Grade


Description

Seco, 02411272, Grooving Insert, Series: 12ER, 12ER Insert, 12150 Insert, 0.059 in Cutting Width, 0.118 in Maximum Depth of Cut, FD Chipbreaker, 0.004 in Corner Radius, 0.25 in Width, 0.472 in Length, Manufacturer's Grade: CP500, Neutral Cutting Direction, Carbide, Material Grade: Micrograin

Specifications

Chipbreaker FD
Corner Radius 0.004 in
Cutting Direction Neutral
Cutting Width 0.059 in
Insert Size 12150
Insert Style 12ER
Length 0.472 in
Manufacturer's Grade CP500
Material Carbide
Material Grade Micrograin
Maximum Depth of Cut 0.118 in
Series 12ER
Width 0.25 in

Includes: Inserts

Country of Origin: India

Standards and Approvals: PROP65

Application:
Especially suitable in intermittent cuts

Features

  • Intended for radial and axial as well as external and internal precision grooving
  • The range of grooving inserts includes inserts for most groove profiles, such as circlip profiles, O-ring profiles, thread undercut and radius grooves
  • Tough micrograin grade intended for finishing to medium-roughing of stainless steels but with wide applicability for example in steels and aluminium alloys
  • Especially suitable in intermittent cuts
