Proto® TorquePlus™ J5531M Standard Length Socket, Metric, 3/4 in Square Drive, 31 mm


Description

Proto® TorquePlus™ Socket, Standard Length, No Impact Rated, Measurement System: Metric, Square Drive, 3/4 in Drive, 31 mm Socket, 56.4 mm Overall Length, 20.5 mm Opening Depth, 43.9 mm Drive End Width, 43.9 mm Socket End Width, Ball Locking, 12 Points, 38.7 mm Bolt Clearance Depth, Alloy Steel, Satin

Specifications

Bolt Clearance Depth 38.7 mm
Drive End Width 43.9 mm
Drive Size 3/4 in
Drive Type Square
Finish Satin
Impact Rated No
Locking Type Ball
Material Alloy Steel
Measurement System Metric
Number of Points 12
Opening Depth 20.5 mm
Overall Length 56.4 mm
Socket End Width 43.9 mm
Socket Size 31 mm
Type Standard Length

Country of Origin: United States

Standards and Approvals: ASME B107.110-2012

Application:
For use on stubborn or damaged fasteners and also on fasteners made from soft materials

Features

  • The TorquePlus™ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners
  • The TorquePlus™ configuration employs a radius corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage
  • The TorquePlus™ internal design minimizes fastener rounding, helps to extend fastener life and allows the user to more easily turn worn, rounded or rusted fasteners
  • Ball detent design
