Martin 35BS19 1/2 Bored-to-Size Type BS Single Pitch Roller Chain Sprocket, 1/2 in Dia Bore, 2.472 in OD, #35 Chain, 19 Teeth, 3/8 in Pitch, Steel


Description

Martin Single Pitch Roller Chain Sprocket, Bored-to-Size Type BS, 1/2 in Bore Dia, 2.472 in Outside Dia, #35 Chain, 19 Teeth, 3/8 in Pitch, 2.278 in, 1.844 in Hub Dia, 1/4-20 x 1/4 in Screw, 1/8 x 1/16 in Keyway, 3/4 in Length Through Bore, Steel

These finished bore sprockets are shaft ready and come complete with keyways and setscrews. The keyways are on center line of the tooth. Bored to size sprockets with 1/2 in bores and smaller are stocked with (2) setscrews only.

Specifications

Bore Diameter 1/2 in
Chain Size #35
Hub Diameter 1.844 in
Keyway Size 1/8 x 1/16 in
Length Through Bore 3/4 in
Material Steel
Number of Teeth 19
Outside Diameter 2.472 in
Pitch 3/8 in
Pitch Diameter 2.278 in
Screw Size 1/4-20 x 1/4 in
Type Bored-to-Size Type BS

Includes: (2) Setscrews

Country of Origin: United States

Standards and Approvals: PROP65: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. For more information: www.P65Warnings.ca.gov

Features

  • Stock finished bores
  • Non-hardened teeth
  • Precise machining and processes ensure consistent finish and high quality
  • Bores are concentric to pitch line, minimizing run out
  • 2 set screws keyed on centerline of tooth
