Martin 120F36 QD Bushed Type C Single Pitch Roller Chain Sprocket, 18.045 in OD, #120 Chain, 36 Teeth, 1-1/2 in Pitch, Steel


Description

Martin Single Pitch Roller Chain Sprocket, QD Bushed Type C, 18.045 in Outside Dia, #120 Chain, 36 Teeth, 1-1/2 in Pitch, 17.211 in, 7 in Hub Dia, 3-5/8 in Length Through Bore, Type F QD® Bushing, Steel

QD (quick detachable)is a sprocket where a tapered bushing is bolted into the taper bore that is machined in the sprocket. When installed this bushing is compressed onto the shaft providing a tight grip.

Specifications

Bushing Type Type F QD®
Chain Size #120
Hub Diameter 7 in
Length Through Bore 3-5/8 in
Material Steel
Number of Teeth 36
Outside Diameter 18.045 in
Pitch 1-1/2 in
Pitch Diameter 17.211 in
Type QD Bushed Type C

Country of Origin: United States

Standards and Approvals: PROP65: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. For more information: www.P65Warnings.ca.gov

Features

  • Manufactured of high carbon steel
  • Precise machining and processes ensure consistent finish and high quality
  • Chain rows are parallel and precisely spaced to increase longevity of sprocket and chain
