Martin 6050 5 Standard Taper Lock Bushing, 5 in Dia Bore, 9-1/4 in Dia Barrel, 5 in OAL, Cast Iron


Description

Martin Taper Lock Bushing, Standard, 5 in Bore Dia, 9-1/4 in Barrel Dia, 17 in (Class 20)/15-1/2 in (Class 30) Hub Dia, 8 deg Taper, 9 in Bolt Circle, 3 Bolt Holes, 1-1/4-7 x 3-1/2 in Screw, 282000 in-lb, For Use With: Taper Bushed Parts, 5 in Overall Length, 1-1/4 x 5/8 in Keyway, Cast Iron

Specifications

Barrel Diameter 9-1/4 in
Bolt Circle Diameter 9 in
Bore Diameter 5 in
Hub Diameter 17 in (Class 20)/15-1/2 in (Class 30)
Keyway Size 1-1/4 x 5/8 in
Material Cast Iron
Number of Bolt Holes 3
Overall Length 5 in
Screw Size 1-1/4-7 x 3-1/2 in
Suitable For Use With Taper Bushed Parts
Taper 8 deg
Torque Rating 282000 in-lb
Type Standard

Includes: Cap Screws and Instruction Sheet

Country of Origin: United States

Standards and Approvals: ANSI B15.1

Features

  • Size 6050 bushing
  • Tolerances meet or exceed industry guidelines and standards
  • TB Bushings are designed for flush mounting and do not have a flange
  • Precise machining and processes ensure consistent finish and high quality
  • Interchangeable with other manufacturers’ taper bushings
