LYON® U2619248 Heavy Duty Rack Upright Frame, 42235 to 12892 lb Capacity, 2 in Center Adjustability, 1650 to 3300 lb, For Use With Pallet Racking System, Steel, Dove Gray


Description

LYON® Rack Upright Frame, Heavy Duty, For Use With: Pallet Racking System, 42235 to 12892 lb Capacity, 2 in Center Adjustability, 1650 to 3300 lb, Steel, Dove Gray, 192 in H x 48 in D

Specifications

Color Dove Gray
Dimensions 192 in H x 48 in D
Material Steel
Specifications 42235 to 12892 lb Capacity, 2 in Center Adjustability, 1650 to 3300 lb
Suitable For Use With Pallet Racking System
Type Heavy Duty

Country of Origin: United States

Features

  • Two frames are required per bay and any number may be joined together in continuous row applications
  • Roll formed upright provides greater strength-to-weight ratio
  • Minimum-sized slots mean more steel per upright
  • Uprights structures are 100% mig welded with precision K-brace and heavy duty cross channel reinforcement for increased strength, rigidity and resistance to abuse
  • Tapered keyhole slots on 2 in centers, provide quick, easy vertical adjustment of beams
  • There are no dead spots or obstructions in upright posts to impede movement of beam along the entire height
  • Lyon pallet rack fits with other traditional teardrop designs, that means you can upgrade damaged, weak, or worn out uprights and beams with our versatile rack, no need to change your whole system
  • Weight capacity based on evenly distributed load - 17200-30200 lb
  • Heavy duty upright posts are 12 ga 3 in W x 3 in D
