Festo 533286 QBL Inch L-Fitting With External Hexagon Socket, 0.098 in Nominal, 10-32 UNF x 5/32 in Push-In Tube, -13.8 to 145 psi Pressure, Polybutylene Terephthalate


Description

Festo L-Fitting, Series: QBL Inch, 0.098 in Nominal, 10-32 UNF x 5/32 in Push-In Tube, 7/16 in Hex, -13.8 to 145 psi, 32 to 140 deg F, Polybutylene Terephthalate

Specifications

End Style 10-32 UNF x 5/32 in Push-In Tube
Hex Size 7/16 in
Material Polybutylene Terephthalate
Nominal Size 0.098 in
Pressure Rating -13.8 to 145 psi
Series QBL Inch
Temperature Rating 32 to 140 deg F

Warranty: 1 Year

Standards and Approvals: FN 940070 CRC-1 Standard, RoHS Compliant

Features

  • 360 deg orientable
  • Pneumatic connection
