Black+Decker® DW618PK Fixed Base Heavy Duty Plunge EVS Router Combo Kit With Soft Start, Toggle Switch, 1/4 in, 1/2 in in Chuck, 8000 to 24000 rpm Speed, 2-1/4 hp, 110 VAC


Description

Black+Decker® EVS Router Combo Kit, Fixed Base Heavy Duty Plunge, Kit, 1/4 in, 1/2 in in Chuck, 8000 to 24000 rpm Speed, 2-1/4 hp, 110 VAC, 12 A, Die Cast Aluminum Housing Material, Overmold Rubber Grip Handle, Black/Silver/Yellow, Toggle Switch

Specifications

Amperage Rating 12 A
Chuck Size 1/4 in, 1/2 in in
Color Black/Silver/Yellow
Handle Type Overmold Rubber Grip
Horsepower 2-1/4 hp
Housing Material Die Cast Aluminum
Speed 8000 to 24000 rpm
Switch Type Toggle
Tool/Kit Kit
Type Fixed Base Heavy Duty Plunge
Voltage Rating 110 VAC

Includes: DW618M Motor Pack, DW6184 Fixed Base, DW6182 Plunge Base, 1/4 in, 1/2 in Collets, Wrench, Sub Base Concentricity Gauge, Large Hole Sub Base, Vacuum Adapter and Heavy Duty Kit Box

Warranty: 3 Years

Country of Origin: United States

Features

  • 2-1/4 hp (maximum motor hp), 12 A electronic variable speed motor provides the power to rout smoothly through the toughest hardwoods
  • Micro-fine depth adjustment ring provides precise depth adjustments in 1/64 in increments and adjusts vertically for a constant switch/cordset location
  • Adjustable, tool free steel motor cam-lock makes depth adjustment and base changes quick and solid locking
  • Quick-release motor latches for fast and easy motor pack removal for bit and base changes
  • Detachable cordset offers cordset serviceability and removes the need for a "shorty" cord motor pack
  • Spindle lock button allows for single wrench bit changes
  • Clear, lexan sub-base provides enhanced base durability, bit visibility and accepts standard template guide bushings
  • Rubber overmolded handles and low center of gravity design provide best-in-class comfort, balance and control
  • Dust sealed switch protects against dust ingestion for longer switch life
  • Heavy duty, precision machined, die cast aluminum base and motor housing for durability and low tool weight
  • Nickel plated motor housing for a smooth, long lasting depth adjustment
  • Right or left switch and cordset location provides the ability to have the switch in your right or left hand
  • Flat top for easy bit and depth changes
  • Self-releasing, long, eight slotted collets for better bit retention and elimination of frozen bits
  • Electronic variable speed with full feedback control for constant speed under load from 8000 to 24000 rpm and soft start to reduce start up torque for enhanced control
  • Integral, through-the-column dust collection collects 95% of the dust and provides superior bit visibility
  • 5-position, adjustable turret stop assists in stepped or repeated plunge cuts
  • Micro-fine depth adjustment on plunge base 5/128 in per turn for precise routing in veneer and inlays
  • Easy to reach plunge lever and switch for superior control while routing
