DeWALT® DW618 Mid Size Soft Start Variable Speed Fixed Base Router Kit, 1/4 in, 1/2 in Chuck, 8000 to 24000 rpm, 2.25 hp, 120 VAC, Toggle Switch


Description

DeWALT® Fixed Base Router Kit, Mid Size Soft Start Variable Speed, Kit Tool/Kit, 1/4 in, 1/2 in Chuck, 8000 to 24000 rpm, 2.25 hp, 120 VAC, 12 A, Aluminum Housing, Knob, Black/Silver/Yellow, Toggle Switch, 10-1/8 in L

The DW618 2-1/4 hp EVS fixed base router with soft start has a powerful motor for routing through tough hardwood at the user's desired speed. Features precise depth adjustments and fast, easy motor pack removal for bit and base changes.

Specifications

Amperage Rating 12 A
Chuck Size 1/4 in, 1/2 in
Color Black/Silver/Yellow
Dimensions 10-1/8 in L
Handle Type Knob
Horsepower 2.25 hp
Housing Material Aluminum
Speed 8000 to 24000 rpm
Switch Type Toggle
Tool/Kit Kit
Type Mid Size Soft Start Variable Speed
Voltage Rating 120 VAC

Includes: DW618M Motor Pack, DW6184 Fixed Base, 1/4 in and 1/2 in Collets and Wrench

Warranty: 3 Years Limited

Country of Origin: United States

Features

  • 2-1/4 hp (maximum motor hp), 12 A electronic variable-speed motor provides the power to rout smoothly through the toughest hardwoods
  • Electronic variable-speed with full feedback control for constant speed under load from 8000 to 24000 rpm and soft start to reduce start up torque for enhanced control
  • Microfine depth adjustment ring provides precise depth adjustments in 1/64 in increments and adjusts vertically for a constant switch/cordset location
  • Adjustable, tool free steel motor cam lock makes depth adjustment and base changes quick and solid locking
  • Quick release motor latches for fast and easy motor pack removal for bit and base changes
  • Detachable cordset offers cordset serviceability and removes the need for a shorty cord motor pack
  • Spindle lock button allows for single wrench bit changes
  • Clear, LEXAN sub-base provides enhanced base durability bit visibility and accepts standard template guide bushings
  • Rubber overmolded handles and low center of gravity design provide best-in class comfort, balance and control
  • Dust sealed switch protects against dust ingestion for longer switch life
  • Heavy duty, precision machined, die cast aluminum base and motor housing for durability and low tool weight
  • Nickel plated motor housing for a smooth, long lasting depth adjustment
  • Right or left switch and cordset location provides the ability to have the switch in your right or left hand
  • Flat top for easy bit and depth changes
  • Self-releasing, long, eight slotted collets for better bit retention and elimination of frozen bits
