Dormer 5976349 E547 Square Shank Straight Flute Pipe Tap, 1/8-28 Thread


Description

Dormer Pipe Tap, Square Shank Straight Flute, Series: E547, Measurement System: Imperial, 1/8-28 Thread, BSPP/Ground Thread Standard, Bottoming Chamfer, 15 mm Thread Length, 59 mm Overall Length, 4 Flutes, Right Hand Cutting Direction, 8 mm Shank Diameter, 8.8 mm Tap Drill, 8 mm Square, HSS, Bright, Medium Hook

Specifications

Chamfer Type Bottoming
Cutting Direction Right Hand
Finish/Coating Bright
Hook Type Medium
Material HSS
Measurement System Imperial
Number of Flutes 4
Overall Length 59 mm
Series E547
Shank Diameter 8 mm
Square Size 8 mm
Tap Drill Size 8.8 mm
Thread Length 15 mm
Thread Size 1/8-28
Thread Standard BSPP/Ground
Type Square Shank Straight Flute

Country of Origin: Brazil

Standards and Approvals: ISO 2284

Application:
For blind and through hole applications

Features

  • A medium alloyed high speed steel that has good machinability and good performance
  • HSS exhibits hardness, toughness and wear resistance characteristics that make it attractive in a wide range of applications
