Dodge® 100530 Single Strand Taper Lock® Type BTL Roller Chain Sprocket With Hardened Teeth, 1/2 in Dia Bore, 2.708 in OD, #50 Chain, 12 Teeth, 5/8 in Pitch, Low-Carbon Steel


Description

Dodge® Roller Chain Sprocket, Single Strand Taper Lock® Type BTL, 1/2 in Bore, 2.708 in OD, #50 Chain, 12 Teeth, 5/8 in Pitch, 2.415 in Pitch Diameter, 1.81 in Diameter Hub, 0.88 in Length Through Bore, Taper-Lock® Bushing, Low-Carbon Steel

Roller chain drives have the ability to handle high shock loads and deliver dependable performance make them the drive of choice for many applications. Dodge® Taper-Lock® sprockets require no expensive or time-consuming re-matching. Their taper-bushing mount automatically compensates for variations in shaft and sprocket machining tolerances. With Dodge® Taper-Lock® sprockets, there are no protruding flanges or screw-heads to take up valuable shaft space. Their compact design provides for more power-dense packages.

Specifications

Bore Diameter 1/2 in
Bushing Type Taper-Lock®
Chain Size #50
Hub Diameter 1.81 in
Length Through Bore 0.88 in
Material Low-Carbon Steel
Number of Teeth 12
Outside Diameter 2.708 in
Pitch 5/8 in
Pitch Diameter 2.415 in
Type Single Strand Taper Lock® Type BTL

Country of Origin: China

Standards and Approvals: ANSI Specified

Application:
Aggregate, Cement, Chemical, Oil, Gas, Food, Beverage, Pharmaceutical, Mining, Paper, Forest, Unit and Baggage Handling Industries, Various Types of Conveyors, Mixers, Blenders, Feeders, Textile Machinery and Packaging Machines

Features

  • No slip transmission
  • Minimal overhung load on shaft bearings
  • Generally used in lower speed ranges
  • Low cost and rugged performance
  • Compact drive design
  • Installs easily
  • Fits shaft securely
  • Allows exact ratio and rating required for your operation
  • Installation-ready, right from the box
  • For 5/8 in pitch single strand chain
  • Hub grooved for chain clearance
