Dixon® FBVG100 Global Ball Valve, 1 in Nominal, FNPT End Style, Forged Brass Body, Full Port


Description

Dixon® Global Ball Valve, Series: FBVG, 1 in Nominal, FNPT, 600 psi, 248 deg F, Full Port, Media: Air/Water, Brass Ball, Forged Brass Body

Specifications

Ball Material Brass
Body Material Forged Brass
End Style FNPT
Media Air/Water
Nominal Size 1 in
Port Type Full
Pressure Rating 600 psi
Series FBVG
Temperature Rating 248 deg F

Standards and Approvals: CSA Certified, UL Listed

Features

  • Forged brass for higher corrosion resistance than steel
  • Plastic covered lever handle for on/off manual control
  • Full port flow for higher operating efficiency than standard port
  • Inline valve for connecting two pipes going in the same direction
  • Female NPT threads for connecting to male threaded pipe fittings
  • Silicone free
